Design Jacquard 2.9 – Professional Jacquard Textile CAD Software

Overview:
Design Jacquard 2.9 is the latest, most advanced version of the renowned Jacquard textile CAD software by Textronic. This professional-grade software is specifically designed for textile designers, weavers, and manufacturers who demand precision, efficiency, and creativity in their fabric designs. Whether you are working with single-layer weaves or complex multi-layered patterns, Design Jacquard 2.9 offers an intuitive, feature-rich environment that streamlines the entire design-to-production workflow.

With real-time fabric simulation, enhanced yarn management, and seamless integration with digital jacquard looms, this software allows you to create high-quality, loom-ready designs while minimizing errors and production costs.

---

🚀 Key Features & Highlights

Advanced Weave Creation

• Generate single- and multi-layered weaves, including intricate satin and twill patterns.

• Use the built-in weave editor and library to create custom textures, simulate fabric behavior, and experiment with unique combinations.

• Auto-generate weaves from imported bitmap images, speeding up the design process and enabling conversion from concept art to loom-ready patterns.

Real-Time Fabric Simulation

• Preview fabrics as they will appear after weaving, with realistic textures, yarn colors, and weave structures.

• Instantly adjust patterns, yarn properties, and color schemes, reducing waste and saving production time.

• Dual-view display for front and back weaves ensures accurate fabric design and evaluation.

Enhanced Color & Yarn Management

• Customize yarn thickness, twist, and color for lifelike fabric visualization.

• Control EPI (ends per inch) and PPI (picks per inch) with precision to match specific loom and production requirements.

• Protect intricate patterns with advanced color shielding during edits.

Pattern Editing & Repeat Options

• Supports straight, cross, and mirror repeats, giving designers full flexibility.

• Grid-based editing with freehand, geometric shapes, and Bezier curve tools ensures precise control.

• Variable brush sizes and multiple undo/redo options provide safe, iterative editing without losing previous work.

Weave Mapper & Float Detection

• Assign specific weaves to different design areas automatically using color mapping.

• Detect excessive warp/weft floats with automated tools, preventing weak points in fabric.

• Dual-view and precision assignment features help visualize how design modifications affect the final fabric.

Seamless Production Integration

• Export loom-ready files directly to jacquard weaving systems.

• Supports both traditional mechanical and modern digital jacquard looms.

• Real-time preview ensures production-ready accuracy, minimizing trial-and-error during manufacturing.

---

🐛 Bug Fixes & Stability Improvements

• Resolved crashes during complex bitmap imports and multi-layer weave generation.

• Fixed minor rendering issues with high-resolution textures and color accuracy.

• Improved simulation stability for smoother real-time previews.

• Optimized loom integration for faster, error-free file exports.

• Enhanced user interface performance for large-scale projects and multi-pattern designs.

---

💻 System Requirements

• Operating System: Windows 10/11 (64-bit) or macOS 11 and above

• Processor: Intel Core i5 or AMD equivalent (Intel Core i7 recommended for large designs)

• RAM: 8 GB minimum, 16 GB recommended for multi-layered fabrics

• Storage: Minimum 2 GB free space for software; additional space for design files

• Graphics: OpenGL 3.3 compatible GPU for real-time simulation and rendering

• Input Devices: Mouse or graphics tablet recommended for precise editing

---

🌟 Benefits & Interesting Facts

• Design Jacquard 2.9 allows designers to experiment with complex patterns that were difficult or impossible with traditional methods.

• Supports eco-friendly design practices by simulating fabrics digitally before actual production, reducing material waste.

• Optimized for both traditional mechanical jacquard looms and modern digital jacquard systems, making it versatile for all production environments.

• The software’s bitmap-to-weave converter enables faster transition from conceptual designs to production-ready patterns.

• Real-time visualization improves workflow efficiency, reduces errors, and ensures that the final fabric matches the original design concept.

• Enables multi-layer weave experimentation, allowing designers to create innovative textures and effects.

---

⭐️⭐️⭐️⭐️⭐️

“As a professional textile designer and developer, I’ve been using Design Jacquard 2.9 for several months, and it has truly transformed my workflow. The software’s advanced weave creation tools and real-time fabric simulation make it effortless to design complex jacquard patterns with precision. I particularly appreciate the bitmap-to-weave conversion feature, which allows me to quickly translate concept designs into loom-ready outputs. The enhanced color and yarn management ensures that every detail of the fabric is accurately represented, saving both time and material during production. Stability improvements and seamless loom integration have made this software a reliable choice for professional textile development. I highly recommend Design Jacquard 2.9 for anyone looking for a top-tier jacquard textile CAD software that combines creativity, efficiency, and accuracy.”
